We are providing you information about paper classification and testing. We are manufacturer of corrugating box making machine if you have any question regarding the paper classification and paper testing then kindly call on +91-9810275497.
Liner | |||||||||||||
Type | Symbol | Gr/M2 | 110 | 125 | 150 | 175 | 200 | 225 | 250 | 275 | 300 | 337 | 400 |
Classes | 2 | 3 | 4 | 5 | 6 | 7 | 8 | 9 | 2 | 4 | |||
Kraft | K | ||||||||||||
Liner | L | ||||||||||||
Test | T | ||||||||||||
Camoscio | C | ||||||||||||
Kraft bianco | KB | ||||||||||||
Liner bianco | LB | ||||||||||||
Test bianco | TB |
Fluiting/ Medium | ||||||||||||
Type | Symbol | Gr/m2 | 75 | 90 | 110 | 125 | 120 | 125 | 140 | 150 | 175 | 180 |
classes | 2 | 3 | 4 | 5 | 6 | 8 | 9 | |||||
Semichimica/scandinava | SS | |||||||||||
Semichmica | S | |||||||||||
Wellenchimica | W | for Light weight card only | ||||||||||
Usochimica | US | for Light weight card only | ||||||||||
Medium | M | |||||||||||
Fluting | F | |||||||||||
Flute | I | H |
A | 8.00 – 0.93 | 4.00- 4.70 |
B | 6.10- 6.51 | 2.40 – 2.80 |
C | 7.31 – 7.96 | 3.48 – 3.95 |
D | 4.75 – 4.80 | 1.86 – 1.94 |
E | 3.20 – 3.60 | 1.13 – 1.40 |
F | 2.38 – 2.40 | 0.64 – 0.90 |
G & N | 1.80 – 2.00 | 0.40 – 0.62 |
K | 11.68 – 12.40 | 6.50 -6.90 |
Dimentions in MM | ||
I | Pitch | |
H | Hight |
Single wall N – F – E – D – B – C – A
Double Wall EB – EC BA – BB – BC DB
Triple Wall BCA – BCK
Paper Testing
BOX COMPRESSION TEST STRENGTH (BCT)
BOND PAPER TEST
Bursting Strength Tester (BST)
Corrugating Medium Test
Water Absorption Test
Edge Crush Test (ECT)
Flat Crush Test (FCT)
Pin Adhesion Test (PAT)
PET Test
Ring Crush Test (RCT)
SXY Test
Tappi Test
VIB Test
