This machine is suitable for various kinds of paper cutting, such as 40-300g copy paper, double adhesive paper, paper-plastic composite material.
| Model | HQJ-1600 two roll |
| Max.Diameter of Unwinding | φ1400mm |
| Max. Cutting Width | 1600mm |
| Cutting Length | 200-500mm |
| Cutting Speed | 50-200times/min |
| Cutting Precision | ±0.2mm |
| Total Power | 9KW |
| Machine Weight | 5KG |
| Machine Size(L*W*H) | 8500*2300*1600 |
| PLC | Panasonic |
| Touch Screen | WeinView |
| The main traction motor | Shanghai 1.5KW |
| Feed motor | YASKAWA3.0KW |
| convertor | Guangdong SINEE |
| Unwinding device | Pneumatic 3 inch air swelling shaft discharge |
| Tension System | Automatic tension |
| EPC | Ultrasonic correction |
| Pneumatic components | Taiwan Mindman |
| Main bearings | Harbin |
| revolving knife | HSS ( two sites ) |
| slitting knife | 7sites |
| fan | 0.75kw |
| Electrical | Schneider |
| switch knob | Schneider |
| Tool |
